Lab: Reusable Subprocess in Aletyx Enterprise Build of Kogito and Drools 10.0.0¶

A reusable subprocess is a BPMN construct that allows process modularization by defining a standalone subprocess that can be invoked from multiple parent processes. Unlike embedded subprocesses, reusable subprocesses are independent and can be executed in different workflows, promoting reusability and consistency across process definitions.

Reusable subprocesses are particularly useful when the same set of activities needs to be performed in multiple processes, such as order validation, loan risk assessment, or customer onboarding.

Lab Overview¶

In this exercise, you will create two BPMN processes:

A reusable subprocess designed for user task-based document validation. This subprocess will serve as a generic validation mechanism that can be reused across different workflows.

A main process for content approval, which will invoke the reusable subprocess. Based on the validation outcome, the main process will print different messages to the system output (sysout).

Supporting Files¶

You have the scafolded project for this lab available in https://github.com/aletyx-labs/kie-10.0.0-lab-sub-reusable. The following POJO is privided for convenience

Document.java¶

This class represents a Document with id, name and content as field.

Instructions¶

Step 1: Clone the Repository¶

Clone the lab project from this repository, which contains all the necessary files and infrastructure for the lab.

Step 2: Import the Project¶

Import the project into VS Code and explore the provided Java classes.

Step 3: Create the reusable subprocess file¶

Create a new file name docReview.bpmn under src/main/resources and open it using the Apache KIE BPMN Editor.

Once file is created, create the process variables that we'll need.

Name	Data Type
document	ai.aletyx.kie.workshop.sub.reusable.Document
review	String

Step 4: Create the reusable subprocess diagram¶

This process should have a simple user task and a script task that will print the result in the console.

In general this is the nodes you'll have to create:

Start Event
Document Review User Task

Task Name: DocumentReview

Groups: managers

Variables - Input Mapping:

Name Data Type Source

document ai.aletyx.kie.workshop.sub.reusable.Document document

review String review

Variables - Output Mapping:

Name Data Type Target

review String review

Log Info Script Task

Script:

    System.out.println("Finished Review: " + review);

End

Step 5: Create the main process file¶

Create a new file name contentApproval.bpmn under src/main/resources and open it using the Apache KIE BPMN Editor.

Once file is created, create the process variables that we'll need.

Name	Data Type
document	ai.aletyx.kie.workshop.sub.reusable.Document
review	String

Step 6: Create the main process diagram¶

This process will start inviking the reusable process, and depending on the result using a XOR gateway, a different script task will be executed.

In general this is the nodes you'll have to create:

Start Event
Review Reusable Subprocess

Called Element: docReview

Abort Parent: checked

Wait for Completion: checked

Variables - Input Mapping:

Name Data Type Source

document ai.aletyx.kie.workshop.sub.reusable.Document document

Variables - Output Mapping:

Name Data Type Target

review String review

Exclusive Gateway: We'll check if the review got an "yes" or not.

On Fail

return !"yes".equals(review);

3.2. Create a Didn't work Script Task

Script:
    ```java
        System.out.println("NOT DONE: " + review);
    ```

3.3. Create an End Event

On Success:

return "yes".equals(review);

3.4. Create a Done Script Task

    Script:
        ```java
            System.out.println("DONE: " + review);
        ```

3.5. Create an End Event

Step 7: Test the Process¶

Run the process in different scenarios.

Step 8: Add a Process Listener¶

Now we'll create our own process listener, we want to check the current riskLevel of the current process instance.

For that we'll first add to the main process contentApproval.bpmn a metadata under Advanced group of the process properties panel:

Name	Value
riskLevel	low

Now we'll create a Java class called MyListener, and we'll list the ProcessStartedEvent! Here's an implementation

Important note: The listener needs to be a valid bean for dependency injection.

import java.util.Map;

import org.kie.api.event.process.ProcessStartedEvent;
import org.kie.kogito.internal.process.event.DefaultKogitoProcessEventListener;

import jakarta.enterprise.context.ApplicationScoped;

@ApplicationScoped
public class MyListener extends DefaultKogitoProcessEventListener {
    @Override
    public void beforeProcessStarted(ProcessStartedEvent event) {
        Map<String, Object> metadata = event.getProcessInstance().getProcess().getMetaData();
        String riskLevel = (String) metadata.get("riskLevel");
        if (riskLevel != null && riskLevel == "low") {
            System.out.println("This is low risk process");
        }
    }
}

If you create a new instance, you should see the message in your console log.

Step 9: Crete your own custom endpoint¶

Kogito automatically creates domain based endpoint, using your process model as reference. However you may not want that, you may want to start your process programatically or expose your own custom endpoint.

In this section we'll disable the rest endpoint generation in the application.properties bvy adding the following line:

kogito.generate.rest=false

And we'll create a new class named MyService - which for the convenience of testing, we'll create a REST endpoint. Here's the code:

import java.util.HashMap;
import java.util.Map;

import org.kie.kogito.Model;
import org.kie.kogito.process.Process;
import org.kie.kogito.process.ProcessInstance;
import org.kie.kogito.process.ProcessService;

import jakarta.enterprise.context.ApplicationScoped;
import jakarta.inject.Inject;
import jakarta.inject.Named;
import jakarta.ws.rs.GET;
import jakarta.ws.rs.Path;

@ApplicationScoped
@Path("/custom")
public class MyService {

   @Inject
   ProcessService processService;

   @Inject
   @Named("contentApproval")
   Process<? extends Model> process;

   @GET
   public void startMyProcessCustomWay() {
        for (int i = 0; i < 2; i++) {
            Model m = process.createModel();
            Map<String, Object> parameters = new HashMap<>();
            parameters.put("document", new Document("id" + i, "name" + i, "content"+i));
            m.fromMap(parameters);

            ProcessInstance<?> processInstance = processService.createProcessInstance((Process)process, null, m, null, null);
            System.out.println("Status:" + processInstance.checkError().variables());
        }
    }
}

Note: in this case we'll create 3 process instances.

Step 10: Exploring GraphQL¶

In this last step, we'll play with GraphQL, and execute a few queries.

First let's list all UserTask for our process:

{
  UserTaskInstances(where: {processId: {equal: "contentApproval"}}) {
    id
    name
    actualOwner
    state
  }
}

Then we'll list all the Process Instances:

{
  ProcessInstances {
    id
    processId
    state
    parentProcessInstanceId
    rootProcessInstanceId
    variables
  }
}
