Lab: Embedded Subprocess in Aletyx Enterprise Build of Kogito and Drools 10.0.0

An embedded subprocess is a key BPMN construct that allows you to group a set of process elements within a parent process, improving readability and modularity. Unlike reusable subprocesses, embedded subprocesses exist only within their parent process and cannot be invoked independently.

A common use case for embedded subprocesses is handling boundary events, such as timers, errors, or escalation events, which enable process designers to define structured exception handling and time-based constraints within a localized section of the workflow. By encapsulating related activities, embedded subprocesses enhance process clarity while providing controlled execution flow and error management.

Lab Overview

You will create a BPMN process for a Loan Application verification for compliance.

1. Get Loan details based on loan id (could be from a Database)
2. Within an embedded subprocesses, we'll evaluate the risk and verify compliance
3. Once verification is done, it'll report using a Script Task
4. However, the subprocesses has the max time of 40 seconds to run, in case of it takes more than 40 seconds, we'll cancel the loan

Supporting Files

The Java services provided in the repository https://github.com/aletyx-labs/kie-10.0.0-lab-sub-embedded contain the infrastructure to support this process. Below is a brief description of each file:

LoanApplicant.java

This class represents a loan applicant and includes basic financial details such as income and expenses.

LoanService.java

A simple service class that provides loan applicant details.

risk.dmn

A Decision Model and Notation (DMN) file used for evaluating loan risk.

Instructions

Step 1: Clone the Repository

Clone the lab project from this repository, which contains all the necessary files and infrastructure for the lab.

Step 2: Import the Project

Import the project into VS Code and explore the provided Java classes.

Step 3: Create the BPMN file

Create a new file name loanApplication.bpmn under src/main/resources and open it using the Apache KIE BPMN Editor.

Once file is created, create the process variables that we'll need.

Name	Data Type
loanId	Integer
applicant	ai.aletyx.workshop.sub.embedded.LoanApplicant
compliance	Boolean

Step 4: Create the process diagram

Our goal is to validate for compliance the loan, for that we'll load Loan infomration, evaluate the risk with DMN and the compliance division will evaluate it. If the compliance takes too long, the loan will be canceled.

In general this is the nodes you'll have to create:

1. Start Event: Initiates the loan validation

2. Collect Loan Information Service Task

   Interface: ai.aletyx.workshop.sub.embedded.LoanService

   Operation: geApplicant

   Variables - Input Mapping:

   Name	Data Type	Source
   param1	Integer	loanId

   Variables - Output Mapping:

   Name	Data Type	Target
   result	LoanApplicant [ai.aletyx.workshop.sub.embedded]	applicant

3. Embedded Subprocess

   3.1. [Sub]Process Variables.

   Note: this variable is only visible within the embedded subprocess

   Name	Data Type
   riskLevel	Integer

   3.1. Start Event

   3.2. Risk Evaluation Business Rules Task

   Rule Language: DMN

   Namespace: https://kie.org/dmn/_6241A03C-45F4-4F24-BD80-BF89B215862F

   Decision Name: Risk

   DMN Model Name: Risk

   Variables - Input Mapping:

   Name	Data Type	Source
   Income	Integer	#{applicant.income}
   Expenses	Integer	#{applicant.expenses}

   Variables - Output Mapping:

   Name	Data Type	Target
   Risk	Integer	riskLevel

   3.3. Compliance Check User Task

   Task Name: Compliance

   Groups: compliance

   Variables - Input Mapping:

   Name	Data Type	Source
   LoanId	Integer	loanId
   Applicant	LoanApplicant [ai.aletyx.workshop.sub.embedded]	applicant

   Variables - Output Mapping:

   Name	Data Type	Target
   Compliance	Boolean	compliance

   3.4. End

4. Report Loan Verified with Script Task

       System.out.println("##################");
       System.out.println("###  VERIFIED  ###");
       System.out.println("##################");
       System.out.println("###  Loan Id:" + loanId);
       System.out.println("###  Complianced:" + compliance);
       System.out.println("##################");


5. End

6. Add Timer event bound to Embedded Sub-processes

Fire once after duration: PT40S

1. Loan Canceled Script Task

       System.out.println("##################");
       System.out.println("###  CANCELED  ###");
       System.out.println("##################");
       System.out.println("###  Loan Id:" + loanId);
       System.out.println("##################");


2. End

Step 5: Test the Process

• Run the process in different scenarios.
